Canon RF-S 10-18mm f/4.5-6.3 IS STM Lens

• Ultra-wide-angle zoom lens for Canon EOS APS-C cameras
• Zoom range of 10-18mm (16-29mm equivalent)
• Wide angle of view for vlogging and selfies
• Outstanding image quality throughout the image, from center to periphery
• Maximum magnification of 0.23x in AF mode and 0.5x in MF mode
• Optical IS with image stabilization effect of 4.0 stops and Coordinated Control IS up to 6.0 stops with cameras equipped with IBIS
• Leadscrew-type STM focus drive for smooth, natural movie AF and focus breathing correction
• Compact and lightweight lens featuring a lens-retraction mechanism
• Can be attached to both APS-C and full-frame EOS R-series cameras without a mount adapter

The RF-S10-18mm F4.5-6.3 IS STM lens combines excellent optics and high performance, providing an ultra-wide angle of view in a compact, portable package, perfect for EOS R cameras with an APS-C sensor. The optical performance directly results from a totally new lens design, highlighted by two Ultra-low Dispersion glass elements and an Aspheric element. The RF-S10-18mm F4.5-6.3 IS STM delivers reliable, speedy, and quiet wide-angle performance, making it an ideal lens for vlogging, video, travel, landscapes, interiors, or simply for creative imagery.

Ultra-wide-angle Lens

The RF-S10-18mm F4.5-6.3 IS STM lens’ wide coverage picks up right where the RF-S standard zooms leave off, at 18mm. From there, it widens to true ultra-wide coverage at its 10mm focal length. This ultra-wide-angle 10-18mm (16-29mm equivalent) is great for shooting in tight spaces where stepping back is difficult, such as vehicles and small rooms, or for landscape, travel, and more.

Wide Angle of View for Selfies and Vlogging

With a wide angle of view for easy shooting indoors and a compact, lightweight design for comfort when filming while out and about, this lens allows you to enjoy taking selfies or vlogging no matter where you’re shooting.

Outstanding Image Quality

The RF-S10-18mm F4.5-6.3 IS STM features a new lens design optimized for short back focus. It has two Ultra-Low Dispersion glass elements and an Apheric element, which achieves high image quality throughout the image from the center to the edges while maintaining compactness. Even at its widest zoom setting, both optical and digital corrections combine to minimize any risk of darkening at the edges or bending straight lines in a scene.

Get Up Close

Capture subjects in large detail with a maximum magnification of 0.23x in AF mode (focusing down to 5.5 inches) and 0.5x in MF mode. This enables richly expressive close-up shots using the wide angle of view and bokeh an ultra-wide-angle lens can provide.

Optical Image Stabilization — Up to 4.0 stops of Shake Correction

To shoot with less blur even without a tripod handy, the RF-S10-18mm F4.5-6.3 IS STM features built-in Optical Image Stabilization, providing up to 4.0 stops of shake reduction even for night shots. When paired with an EOS R-series camera that has In-Body Image Stabilization (IBIS), the Coordinated IS allows for up to 6.0 stops of correction. With less equipment to carry, this makes hand-held video, travel photography, or even taking everyday shots convenient.

High-speed, Smooth, and Quiet Autofocus

The lens features a leadscrew-type STM focus drive system, which provides smoother and more natural movie AF. This is especially beneficial to video users because of its combination of quiet operation and outstanding smoothness of focus changes during actual recording. Plus, it supports focus breathing correction, in which the camera digitally corrects for changes in the angle of view caused by focus movement during video recording.

Compact and Lightweight

At approximately 5.3 ounces (150g), the RF-S10-18mm F4.5-6.3 IS STM is extremely lightweight and compact. The lens also features a lens-retraction mechanism that works without a switch, allowing it to be stored compactly simply by turning the zoom ring for outstanding portability.

SPECS:

• Focal Length: 10-18 mm (equivalent to 16-29 mm in 35 mm format)
• Maximum and Minimum Aperture: f/4.5 - f/32
• Lens Mount Type: RF Mount
• Compatible Cameras: Canon EOS R-series, full-frame and APS-C
• Minimum Focusing Distance:
• AF: 0.14 m / 5.5 in. (at 10-18 mm)
• MF: 0.086 m / 3.4 in. (at 10 mm)
• Maximum Magnification:
• AF: 0.23x (at 18 mm)
• MF: 0.5x (at 10 mm)
• Field of View:
• AF: Approx. 165 × 110 mm / 6.5 x 4.3 in. (at 10 mm) to approx. 96 × 64 mm / 3.8 x 2.5 in. (at 18 mm)
• MF: Approx. 45 × 30 mm / 1.8 x 1.2 in. (at 10 mm) to approx. 96 × 64 mm / 3.8 x 2.5 in. (at 18 mm)
• Angle of View (Diagonal): Approx. 107° 30’– 74° 20'
• Lens Construction: 12 elements in 10 groups
• Special Elements: 2 UD lenses and 1 aspheric lenses
• Lens Coating: Canon SSC (Super Spectra Coating)
• Filter Size Diameter: ø49 mm
• Aperture Blades: 7
• Image Stabilization: 4.0 stops correction with In-lens Optical Image Stabilization (6.0 stops correction with EOS R series in-body coordinated Image stabilization)
• Maximum Outer Diameter x Length: Approx. ø2.7 in. (ø69mm) x 1.8 in. (44.9mm) (retracted)
• Weight: Approx. 5.3 oz. / 0.33 lbs. / 150g
