Sea & Sea MDX-7D Housing for Canon 7D
Sea & Sea MDX-7D Housing for Canon 7D
Unparalleled design provides easy access to the main dial and the quick control dial. Shutter speed and aperture can be adjusted without removing your hand from the grip.
SKU: # ss-06152
Price $3,799.95
This product has been discontinued. Please scroll down for accessories and other options.
Custom Options
Optional Sea and Sea 45 Degree Viewfinder
Standard viewfinders reduce original image size for full view of the corners and shooting data. The Sea and Sea 1.2x SLR 45 Degree Viewfinder is a prism optic that greatly magnifies original image size and thus reduces eye strain and improves composition. The Sea and Sea 45 rotates for vertical use. Price includes custom installation.
Price as Configured
Articles & Videos About This Item ALL ARTICLES ALL VIDEOS
Overview / Product Description
Sea & Sea MDX-7D Housing for Canon 7D
Unparalleled design provides easy access to the main dial and the quick control dial. Shutter speed and aperture can be adjusted without removing your hand from the grip. Button to activate live view photography and video is ergonomically positioned for easy access. While holding the grip, you can control AE lock / Index / Reduce lever and AF point selection / Magnify lever and AF start lever to check focus points and then press the start / stop button to record video. The setting button is also situated close to the grip for quick access to the button. Great functionality, engineering and ergonomic design make this housing exceptional.
Replacement of the strobe sync connector (6-pin wired to 2-pin wired)Consult a SEA&SEA authorized service center for the details.Customizing the housing offers additional functions. You can replace the 6-pin wired TTL converter connector on the top of the housing with a 2-pin wired strobe connector for an additional cost. This modification provides two 2-pin wired strobe connectors so you can connect two SEA&SEA YS-Series strobes.
By attachment of a 45_ viewfinder (view magnification of 1.2x) with Amici prisms to the eyepiece on the housing, the magnification increases to 1.2x, allowing the entire field of view to be seen clearly. Recommended for users committed to strict compositioning and focusing.
Simply by connecting the Fiber-Optic Cable (L-type) to the connector, the light of the digital cameras built-in flash is detected and connected to an external strobe. This is considerably less complicated than setting up an electrical connector that requires detailed knowledge. It also eliminates any risks involved when the connector is submerged in water.
Unparalleled design provides easy access to the main dial and the quick control dial. Shutter speed and aperture can be adjusted without removing your hand from the grip. Button to activate live view photography and video is ergonomically positioned for easy access. While holding the grip, you can control AE lock / Index / Reduce lever and AF point selection / Magnify lever and AF start lever to check focus points and then press the start / stop button to record video. The setting button is also situated close to the grip for quick access to the button. Great functionality, engineering and ergonomic design make this housing exceptional.
Specs:
Unparalleled design provides easy access to the main dial and the quick control dial. Shutter speed and aperture can be adjusted without removing your hand from the grip. Button to activate live view photography and video is ergonomically positioned for easy access. While holding the grip, you can control AE lock / Index / Reduce lever and AF point selection / Magnify lever and AF start lever to check focus points and then press the start / stop button to record video. The setting button is also situated close to the grip for quick access to the button. Great functionality, engineering and ergonomic design make this housing exceptional.
Replacement of the strobe sync connector (6-pin wired to 2-pin wired)Consult a SEA&SEA authorized service center for the details.Customizing the housing offers additional functions. You can replace the 6-pin wired TTL converter connector on the top of the housing with a 2-pin wired strobe connector for an additional cost. This modification provides two 2-pin wired strobe connectors so you can connect two SEA&SEA YS-Series strobes.
By attachment of a 45_ viewfinder (view magnification of 1.2x) with Amici prisms to the eyepiece on the housing, the magnification increases to 1.2x, allowing the entire field of view to be seen clearly. Recommended for users committed to strict compositioning and focusing.
Simply by connecting the Fiber-Optic Cable (L-type) to the connector, the light of the digital cameras built-in flash is detected and connected to an external strobe. This is considerably less complicated than setting up an electrical connector that requires detailed knowledge. It also eliminates any risks involved when the connector is submerged in water.
Unparalleled design provides easy access to the main dial and the quick control dial. Shutter speed and aperture can be adjusted without removing your hand from the grip. Button to activate live view photography and video is ergonomically positioned for easy access. While holding the grip, you can control AE lock / Index / Reduce lever and AF point selection / Magnify lever and AF start lever to check focus points and then press the start / stop button to record video. The setting button is also situated close to the grip for quick access to the button. Great functionality, engineering and ergonomic design make this housing exceptional.
Specs:
- Controls almost all of the Canon EOS 7D essential functions underwater.
- Every detail of the housing is precision machined from a solid aluminum block to achieve a high-quality texture and design. All edges have been polished carefully for safety.
- The housing is protected by a highly corrosion resistant, anodized coating. The coating protects the housing from environmental corrosion and abrasions.
- A new type of easily operated shutter lever, excellent for taking quick snapshots and for avoiding motion blur. The shutter lever can be operated in two ways by pushing from the top or pulling from the front and offers a smooth option for adjusting the autofocus by pressing the button halfway down so you need not worry about any missed chances.
- TTL auto adjustment available when using an optional YS Converter/C. When using a YS Converter/C to enable the TTL auto adjustment, use a 5-pin Sync Cord/N to connect it to a genuine SEA&SEA strobe.
- Furnished with a tripod socket in the central region of the bottom surface of the main body. If you remove the attached Ergo Grip, you can also add an optional Grip-Stay L.
- Comes standard with two bulkhead connectors: one type-N connector (2-pin wired for manual) and one 6-pin wired connector (for dedicated TTL).
- Equipped with a Optical Viewfinder 0.5x standard. Interchangeable 0.66x/0.8x viewfinders (optional) are also available.
- The quick shoe makes the camera easy to install and remove from the housing. The camera is firmly and correctly mounted on the quick shoe with the tripod screw hole and the positioning pin.
- A built-in leak sensor immediately alerts you to any water leakage.
- Strong and durable build, with a depth rating of up to 60m / 200ft.
- The MDX-7D housing comes from the factory with these type-N connectors: one 2-pin wired connector and one 6-pin wired connector.
- To use two SEA&SEA YS-Series strobes with the factory-equipped type-N connectors, you must use the 5-pin Dual Sync Cord/N.
