Gates Red Raptor Underwater Housing Body Pro Raptor PR

A NEW LEVEL OF USABILITY AND PERFORMANCE IN UNDERWATER IMAGING

Start with everything that is a Gates - reliable design, adaptability, no compromises optics, perfect buoyancy/trim, legendary factory support - and add valuable, new, intimate features. The result is PRO RAPTOR—a dedicated, purpose-built underwater housing for RED V-RAPTOR.

Blurring the lines between camera and housing, PRO RAPTOR pioneers practical new features: RT73 'cable-less' External Monitor; directed internal cooling; Seal Check Lite Rechargeable; extended versatility for practically any application, and optimal size for both travel and in-water stability. Gates Command / Control module is standard with PRO RAPTOR, providing direct access to a wide variety of RED RAPTOR camera functions like presets, focus and exposure tools, ISO/frame rate/shutter change, white balance, camera shutdown, and more.

Despite such advanced new features, PRO RAPTOR remains loyal to the extensive suite of legacy Ports, Port Adapters, and Stackable Port Rings. As always, Gates defends your ROI.

Like its predecessor, DEEP WEAPON, PRO RAPTOR is a versatile, adaptable underwater rig. It serves cinema, TV, Natural History, documentary, research, military, and countless other applications. For working professionals, failure is not an option. Don't take a chance—take a Gates!

Compatible cameras:

• V-RAPTOR 8K VV
• V-RAPTOR 8K S35
• V-RAPTOR [X] 8K VV

KEY FEATURES

• COMPLETE CAMERA CONTROL: The camera side menu/display plus the Gates user-assignable Command / Control module provide an unprecedented level of camera control.
• OPTIMAL SIZE FOR TRAVEL AND STABILITY: PRO RAPTOR is designed to meet the demands of natural history world travelers and cinema / TV professionals who require steady, stable sequences.
• "CABLE-LESS" RT73 EXTERNAL MONITOR: A genuinely innovative design specifically for RED DSMC3 RED TOUCH 7.0. The RED USB-C RMI cable passes through a sealed tilt/swivel mount, and is user-replaceable.
• DIRECTED INTERNAL COOLING: An internal fan keeps the RAPTOR camera happy. It is also forward-facing, circulating air through the port area to eliminate dome fogging.
• FLEXIBLE, ADAPTABLE: PRO RAPTOR is a chameleon, suitable for practically any shooting situation. It has a wide variety of options and accessories for natural history, TV, commercials, cinema, research, military, surveys, and more. Whatever your application, PRO RAPTOR will assist.
• PROFESSIONAL HANDLING: Built-in handgrips make above-water handling and underwater manipulation a breeze.
• GATES SDI EXTERNAL MONITOR OPTIONS: PRO RAPTOR supports any Gates SDI-type External Monitor such as:
  • EM5 ULTRA for SmallHD Ultra 5
  • EM7 CINE for SmallHD Cine 7
  • EM503 for SmallHD 503 Ultrabright
• PRECISION PORTS: PRO RAPTOR supports the entire Gates suite of 6, 8, and 10" dome and flat ports. It offers AR-coated glass or acrylic / Perspex options.
• SURFACE COMMAND / CONTROL: PRO RAPTOR would not be complete without consideration for surface tethers. Universal bulkhead adapters utilize both Gates MultiConn and Pass-Through designs for SDI and data connections to the surface.
• SEAL CHECK LITE RECHARGEABLE: Gates introduced Seal Check-in 2008, providing integrity certainty and the ultimate in reliability. "Know Before You Go" is now rechargeable using 2x 18650 batteries for a super long life.
• FAN ON / OFF SWITCH: Quiet on Set! PRO RAPTOR cooling fan can be turned off when needed.
• REMOTE RECORD TRIGGER INPUT: Another Gates first: standardized 3.5mm receptacle for remote record trigger applications.
• EXTENSIVE LENS SUPPORT: Nothing comes close to Gates's range of lens support. RF / EF / PL / LPL and more are entirely usable in PRO RAPTOR.
• ADJUSTABLE BUOYANCY AND TRIM: Add /remove trim weights for ideal buoyancy and balance, which are key to stable, fluid shots.
• IT'S INCLUDED: No need to buy piece-by-piece. PRO RAPTOR includes Seal Check Lite Rechargeable, spare kit, tool kit, Lens Gear Drives, system cabling, carry handle, and more. Just add port (s) and Port Ring(s) specific to your application to make a complete kit.
• 2-YEAR WARRANTY LEGENDARY FACTORY-DIRECT SUPPORT: Gates is synonymous with reliability and support, and only Gates offers a 2-year, renewable warranty on all housings.
• FIELD SERVICEABLE: Gates products are nearly 100% serviceable in the field.
• CUSTOMIZE. ONE SIZE DOES *NOT* FIT ALL.: Have a unique application? Shooting style? Special setup needs? Gates routinely custom-modifies housing to your requirements- just how you want it.

SPECIFICATIONS

CONTROLS

• Power
• Record
• Record Trigger (remote input, at fingertip)
• Record Control (physical camera button push)
• Camera control
• Complete side camera menu navigation and user buttons
• Gates COMMAND / CONTROL (GCC-RP) for DSMC3
• Lens Control
• Mechanical Lens Gear Drives - Focus / Zoom / Iris
• GCC Iris control of Canon EF and RF lenses

DIMENSIONS

• PRO RAPTOR Dimensional Drawing

CONSTRUCTION

• Machined Aluminum, Type III Hard Anodized finish
• Stainless steel hardware

WEIGHT IN AIR

• Variable depending on configuration.
• Complete: 42.3 lbs Camera/Batty/LCD/SPR80-200/SP80 Glass/RT73
• Transport: 20.6 lbs housing only with Port Base

WEIGHT IN WATER

• Fully adjustable to be neutral / trim with Gates trim system

DEPTH RATING

• 350 feet / 107 meters

WARRANTY

• 2 Years Renewable. Gates Warranty Details
